Fully hydraulic control, effortless and precise operation
High-lift unloading allows direct loading into mixers or trucks
Compact and flexible, suitable for confined spaces
Powerful engine, high load capacity
This small tracked dump truck features a fully hydraulic control system. Both the lifting and tipping of the cargo bucket are controlled by hydraulic cylinders, ensuring smooth operation and ease of use; one person can complete the loading and unloading tasks. The maximum unloading height reaches 1.05 meters, with ample ground clearance, allowing materials to be directly poured into mixers, small dump trucks, or collection boxes, significantly reducing secondary handling. The cargo bucket has a 200-liter capacity and a maximum load capacity of 500 kg. Combined with a 90° hydraulic tipping angle, unloading is clean and thorough. The vehicle is equipped with 180mm wide rubber tracks, providing low ground pressure and a 110mm ground clearance, enabling a 20° climbing ability, adapting to complex conditions such as mud and slopes. With a body width of only 700mm and a minimum turning radius of 1.15 meters, it can easily enter narrow alleys, indoor construction sites, or orchards. Whether it's concrete, gravel, earthwork, or livestock manure and garden waste, this truck can efficiently complete the transfer.
| JINING YUANHENG MACHINERY MANUFACTURING CO.,LTD | |
| Track data | |
| track width: | 180 |
| Track grounding length: | 1000 |
| Chassis ground clearance: | 110 |
| Hopper | |
| Cargo box Capacity | 200 |
| Tipping Systme | Hydraulic Tipper |
| Tilting Angle | 90 |
| Walk | |
| Walking Speed | 2.88 |
| Minimum Turning radius | 1150 |
| Track gauge | 520 |
| Climbing abillty | 20 |
| Engine options | |
| Engine model: Emission | 马力/转速rpm |
| Science Popularization 173 (Diesel) Euro V | 5.5HP/3600 |
| Runtong (hand-operated starter) EPA Euro 5 | 7HP/3600 |
Small construction sites: Transporting cement and gravel to mixers or elevated hoppers.
Orchards: Transporting fertilizer and picking baskets, adaptable to narrow row spacing.
Livestock farms: Cleaning and high-level unloading into manure collection trucks.
Municipal sanitation: Collecting household waste and fallen leaves and unloading them into large garbage trucks.
Interior decoration and demolition: Access via elevators or narrow doors; removal of broken bricks and debris.
Mountainous or sloping farmland: 20° climbing ability to handle undulating terrain.
Q1: What is the maximum unloading height of this vehicle?
A: The unloading height can reach 1050mm. When the cargo bucket is raised to its highest position, the bottom is 1.2 meters above the ground, easily connecting to the feed inlet of a concrete mixer or the cargo bed of a small truck.
Q2: What does "fully hydraulic system" mean? What are its advantages?
A: The lifting and tipping of the cargo bucket are driven by hydraulic cylinders, eliminating the need for manual tipping. The advantages include easy operation, smooth lifting, and precise control of the unloading height and angle, making it especially suitable for heavy-load or frequent unloading scenarios.
Q3: Can I choose a diesel version? Does it meet European and American emission standards?
A: Yes. We offer the KEP173 diesel engine (Euro 5 emission standard) and the Runtong gasoline engine (EPA/Euro 5), both designed for low emissions and export to European and American markets.
Q4: Are the rubber tracks durable?
A: The 180mm rubber tracks are wear-resistant and anti-aging, suitable for cement roads, brick floors, muddy roads, and gravel roads.
Q5: Can it turn on the spot?
A: With a minimum turning radius of only 1.15 meters, combined with dual track forward and reverse control, it can turn on the spot in narrow areas, making it very flexible.
